Airtac MK Series Multi-position Locking Cylinder MK16X30
The AirTAC Airtac MK Series Multi-position Locking Cylinder MK16X30 is a genuine MK multi-mount cylinder (double acting), 16 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 100.5 N of push force at 0.5 MPa. A bumper cushions the impact. As an MK unit a fixed rod stops the piston rod rotating.
- TypeMulti-mount, double acting
- SeriesMK (no-rotating)
- Bore16 mm
- Push thrust @0.5 MPa100.5 N
- Operating pressure0.15 - 1.0 MPa (22 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWithout magnet
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MK Series Multi-position Locking Cylinder MK16X30
The MK16X30 is an AirTAC MK series multi-mount cylinder with a 16 mm bore and 30 mm stroke. Its square body fixes from 6 directions (front, back, left, right, top and bottom), so cylinders can sit side by side to save space, and magnetic-switch slots are machined around the body. As a double acting MK cylinder it produces about 100.5 N of theoretical push force at 0.5 MPa on this bore, and the built-in bumper cushions the stroke at both ends.
This is a genuine AirTAC part. The MK family is the no-rotating version: a fixed rod and plate keep the piston rod from turning, in contrast to the standard MD series where rotation is allowed. This SKU is supplied without a magnet (no S suffix) and with PT thread ports (M5x0.8 on this bore). We can confirm dimensions and sizing from the datasheet on request.
Airtac MK Series Multi-position Locking Cylinder MK16X30 Technical Specifications
| Model | Airtac MK Series Multi-position Locking Cylinder MK16X30 |
|---|---|
| Type | Multi-mount cylinder, double acting |
| Series | MK (no-rotating) |
| Bore | 16 mm |
| Push thrust @0.5 MPa | 100.5 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | Without magnet |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.15 - 1.0 MPa (22 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 30 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Select the 16 mm bore when about 100.5 N theoretical push at 0.5 MPa (86.4 N pull side) suits your task; choose 20, 25 or 32 mm bore for higher thrust. MK is the choice when the rod must not rotate; MD is the standard type otherwise. This is a double acting unit and the 30 mm stroke is within the bore 16 table (up to 50 mm) - remember the short covers are not meant for over-long strokes. No magnet is fitted on this SKU; add the S suffix for one. Thread is PT, with G as an option. Confirm side-load capacity from the datasheet.
Applications
Eject and discharge
Mounted under a chute with the body fixed from its top face, the non-rotating rod ejects parts cleanly on the 30 mm stroke without twisting.
Assembly jig locating
Bolts side by side in an assembly jig to locate and hold components, with switch slots around the body for position checking.
Line stopper actuation
Acts as a stopper on a small-parts conveyor, extending across the flow with about 100.5 N push force at 0.5 MPa and bumper cushioning.
FAQ
How much force does the MK16X30 produce, and how does it compare with single acting versions?
As a double acting 16 mm bore cylinder it delivers about 100.5 N theoretical push at 0.5 MPa and about 86.4 N on the pull side. Single acting MSK/MTK versions of this bore produce less (about 70.4 N push at 0.5 MPa), so do not mix the figures - check the acting type of the model you are buying.
How does the 6-direction mounting help my machine layout?
The square multi-mount body fixes from 6 directions (front, back, left, right, top and bottom), so the same cylinder can be mounted upright, inverted or laterally, and several units can sit side by side to save space. For exact body dimensions at this 30 mm stroke and allowable side-load, confirm from the datasheet.
