Airtac MK Series Multi-position Locking Cylinder MK16X35
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK Series Multi-Position Locking Cylinder MK16X35 Technical Details
- Model: MK16X35
- Type: Compact multi-position pneumatic locking cylinder
- Bore size: 16mm
- Stroke: 35mm (±17.5mm adjustable)
- Operating pressure: 0.1–0.9 MPa
- Locking positions: 3 (center + both ends)
- Locking force: 38N at 0.5 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable rubber buffers
- Mounting types: Basic (MB), Front flange (MF1), Rear flange (MF2)
- Port size: M5x0.8 (dual ports)
- Rod material: Stainless steel (SUS304)
- Cylinder tube: Aluminum alloy (hard anodized)
- Seals: NBR standard (optionally available in FKM)
- Weight: 650g ±5% (without accessories)
- Dimensions: 137mm(L) × 32mm(W) × 32mm(H) (retracted state)
- Extended length: 172mm (full stroke)
- Repeat positioning accuracy: ±0.2mm
- ISO standard: 6432
The MK16X35 features a unique mechanical locking mechanism with magnetic position detection slots. Its twin-piston design enables stable intermediate stops without air consumption during holding phases. The cylinder incorporates wear-resistant guide bushings and IP54-rated dust protection, making it suitable for dirty environments. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 4).
- Precision workpiece clamping in CNC rotary tables
- Position locking for robotic tool changers
- Stage positioning in semiconductor handling systems
- Safety interlocks in automated packaging lines
- Multi-height adjustments in medical bed mechanisms
- PCB board holding/fixturing during SMT assembly
Installation tip:
Ensure proper alignment of magnetic sensors (SN-04N series recommended) within 2mm
of cylinder body. Apply light machine oil (ISO VG32) monthly through air line lubricator.
Avoid side loads exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | MK16X35 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 35mm |
