Airtac MK Series Multi-position Locking Cylinder MK16X40
2. Features multiple body mounting configurations for simplified installation;
3. Gang-mounting capability enables multi-cylinder integration, optimizing space utilization in compact layouts;
4. Precision-guided piston rod design eliminates the need for external lubrication;
5. Integrated piston rod locking block ensures anti-rotation stability;
6. Extensive model selection across standardized specifications;
7. Optional high-temperature sealing materials support operation at 0~150℃ (optional feature).
Category: Multi-Position Fixed Cylinders | Brand: AIRTAC | Series: MK
AirTAC MK Multi-Position Locking Cylinder MK16X40 Technical Details
- Model: MK16X40
- Bore size: 16mm
- Stroke: 40mm
- Operation: Double-acting with mechanical locking
- Working pressure: 0.05-1.0 MPa
- Locking positions: 3 fixed positions (extended/mid/retracted)
- Medium temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard), G1/8 optional
- Cushioning: Adjustable pneumatic cushion
- Body material: Aluminum alloy (anodized)
- Rod material: Chrome-plated steel
- Seal material: NBR (nitrile rubber)
- Weight: 680g ±2%
- Dimensions: 165mm(L) × 42mm(W) × 42mm(H)
- Mounting type: Front flange (ISO 15552 standard)
- Repeat positioning accuracy: ±0.2mm
- Protection class: IP54 (standard), IP67 optional
Precision multi-station cylinder featuring mechanical locking mechanism for intermediate position holding without continuous air supply. The hardened stainless steel guide rod ensures wear resistance in high-cycle applications. Integrated magnetic sensor grooves (M5x0.5 thread) enable position feedback installation.
- Rotary index table positioning in CNC machinery
- Tool changing mechanisms in automated manufacturing cells
- Clamping sequence control in injection molding
- Workpiece staging in semiconductor wafer handling
- Safety interlocks in press brake operations
Installation protocol:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Avoid side load exceeding 15N. For vertical mounting,
install locking release valve in accessible position.
| Property | Property Value |
|---|---|
| sku | MK16X40 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <40mm> |
