Airtac MPEF Embedded Mounting Threaded Cylinder MPEF12X5
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF Series Thread-Embedded Cylinder MPEF12X5 Technical Details
- Model: MPEF12X5
- Bore size: 12mm (standard metric series)
- Stroke: 5mm (X5 stroke code)
- Installation type: Flush-mounted with dual threaded ports
- Operation: Double-acting
- Working pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Temperature range: -10℃ to 70℃ (14°F to 158°F)
- Port size: M5x0.8 threaded (dual ports 180° opposed)
- Cushioning: Adjustable rubber buffer
- Seal material: NBR (Nitrile) standard / optional FKM
- Piston rod thread: M5x0.5 external thread
- Protection rating: IP40 (dust protected)
- Weight: 0.18kg (without accessories)
- Dimensions: 65mm(L) × 32mm(W) × 32mm(H) (body only)
- Max theoretical force: 7.2N at 0.63MPa (extending)
- Air consumption: 0.15L/min at 0.5MPa (single cycle)
Ultra-compact embedded cylinder designed for direct machine mounting via threaded ports (M5x0.8). Features anti-rotation design with dual guide slots and chromium-plated piston rod. Requires minimal installation depth (flush mounting) with 0.2mm maximum permissible lateral load. Lubrication-free operation when using AirTAC P1 series air treatment units.
- Precision clamping in semiconductor wafer handling
- Micro-positioning in optical lens manufacturing
- Valve actuation in portable medical devices
- Compact automation in 3D printer mechanisms
- Miniature assembly systems for electronics
Installation protocol:
Use torque-controlled tightening (0.49–0.69N·m for M5 threads).
Maintain 0.5mm minimum clearance around cylinder body during embedded installation.
Always install with rod end facing downward in vertical applications.
Critical notes:
Not suitable for side load applications exceeding 0.5N.
Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 standards.
Maximum permissible lateral misalignment: ±0.3mm.
| Property | Property Value |
|---|---|
| sku | MPEF12X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Cushion Type | Non-cushioned |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
