Airtac MPEF Embedded Mounting Threaded Cylinder MPEF6X10N
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF6X10N Embedded Threaded Cylinder Specifications
- Model: MPEF6X10N
- Type: Double-acting embedded thread cylinder
- Bore size: 6mm
- Stroke: 10mm
- Installation: Flush-mounted threaded body
- Operating pressure: 0.05–0.9 MPa
- Port size: M5×0.8 (standard)
- Cushioning: Adjustable pneumatic cushion
- Temperature range: -10℃ to 80℃
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Thread type: Metric fine thread (internal mounting)
- Weight: 0.12kg ±3%
- Dimensions: 90mm(L) × 28mm(W) × 28mm(H)
- Rod end thread: M3×0.5 (external)
- Max theoretical thrust: 27.6N @0.5MPa
- Lubrication: Pre-lubricated (grease retention design)
- Protection rating: IP54 (standard sealing)
Ultra-compact cylinder designed for space-constrained embedded installations. Features precision-machined internal threads (M6×1.0) for direct mounting without brackets, reducing overall system footprint. The dual piston seal design ensures consistent performance in high-cycle applications. Requires dry filtered air with 25μm filtration minimum.
- Miniature automation systems in electronics assembly
- Precision clamping mechanisms in semiconductor handling
- Medical device actuation systems
- Compact packaging machine components
- Robotic end-effector positioning
Installation guidelines:
Use torque-controlled installation (max 1.2N·m) to prevent thread deformation.
Maintain coaxial alignment within ±0.5° during mounting. For vertical installations,
recommend adding external guide mechanisms for heavy side loads.
| Property | Property Value |
|---|---|
| sku | MPEF6X10N |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Non-threaded |
| Cushion Type | Non-cushioned |
| Bore Diameter | <6mm> |
| Stroke | <10mm> |
