Airtac MPEF Embedded Mounting Threaded Cylinder MPEF6X15
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF6X15 Embedded Threaded Cylinder Specifications
- Model: MPEF6X15
- Type: Embedded mount thread cylinder (double-acting)
- Bore size: 6mm
- Stroke: 15mm
- Mounting type: Embedded screw-in installation
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Port thread: M5x0.8
- Cushioning: Adjustable buffer (both ends)
- Seal material: Heat-resistant NBR
- Protection rating: IP54
- Piston speed: 50–700 mm/s
- Weight: 0.08kg
- Dimensions:
- Total length (L): 63mm
- Body width (W): 20mm
- Mounting flange height (H): 8mm
- Mounting hole spacing: 12mm (center-to-center)
- Mounting bolt: M3x6 (stainless steel included)
Ultra-compact embedded cylinder designed for space-constrained automation systems. Features precision-machined aluminum alloy body with anti-corrosion treatment and self-lubricating guide bushings. The embedded mounting design allows direct screw-in installation without additional brackets, reducing overall system footprint by 40% compared to standard cylinders.
- Micro-pneumatic grippers in SCARA robots
- Precision valve actuation in analytical instruments
- Semiconductor wafer handling equipment
- Dental chair positioning mechanisms
- Compact jig clamping in watch manufacturing
Installation guidelines:
Use thread lock adhesive (Loctite 243 recommended) during mounting.
Ensure perpendicular installation tolerance ≤0.5°. Lubricate with ISO VG32 turbine oil
before initial operation. Avoid side loads exceeding 2N·m.
- Air filtration: 5μm minimum
- Lubrication: Oil-mist lubrication (ISO VG32 or equivalent)
- Max lateral load: 1.5N
- Cycle life: 2,000km travel distance (NBR seals)
| Property | Property Value |
|---|---|
| sku | MPEF6X15 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Cushion Type | Non-cushioned |
| Bore Diameter | <6mm> |
| Stroke | <15mm> |
