Airtac MPEF Embedded Mounting Threaded Cylinder MPEF6X15N
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF Flush-Mount Threaded Cylinder MPEF6X15N Specifications
- Model: MPEF6X15N
- Type: Single-acting spring return (push type)
- Bore size: 6mm
- Stroke: 15mm
- Mounting style: Flush-mount thread (M5x0.8 internal thread)
- Operating pressure: 0.05–0.7 MPa
- Operating temperature: -10℃ to 70℃
- Cushioning: Adjustable air cushion
- Port size: M5x0.8
- Barrel material: Aluminum alloy (hard anodized)
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 38g ±2g
- Dimensions:
- Total length (extended): 56mm
- Body length: 41mm
- Width: 20mm (hexagon mounting surface)
- Height: 20mm (including mounting threads)
- Protection rating: IP54 (standard)
- Lubrication: Pre-lubricated (DOP-free grease)
Ultra-compact threaded cylinder designed for space-constrained automation applications. Features precise positioning capability with integrated mounting threads that allow direct installation without additional brackets. The corrosion-resistant construction and self-lubricating seals ensure maintenance-free operation in cleanroom environments. Requires filtered air (5-40μm) with ISO 8573-1:2010 Class 3.2.3 quality.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms in optical lens production
- Valve actuation in analytical instruments
- Medical device positioning systems
- Miniature conveyor stoppers in packaging lines
Installation note:
Use 0.5-1.5Nm torque for mounting screws. Maintain 2mm clearance around cylinder body for heat dissipation.
For vertical installations, orient piston rod downward to prevent debris accumulation.
Avoid side load exceeding 2N. For lateral force applications,
specify MPEF-R series with reinforced guide mechanism.
| Property | Property Value |
|---|---|
| sku | MPEF6X15N |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Non-threaded |
| Cushion Type | Non-cushioned |
| Bore Diameter | <6mm> |
| Stroke | <15mm> |
