Airtac MPEF Embedded Mounting Threaded Cylinder MPEF6X5
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF6X5 Embedded Flange Mount Threaded Cylinder Specifications
- Model: MPEF6X5
- Type: Double-acting embedded flange cylinder
- Bore size: 6mm (0.24")
- Stroke: 5mm (standard)
- Mounting style: Flush embedded (ISO 21287 compliant)
- Port thread: M5×0.8 (PT1/8 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushion type: Adjustable rubber bumper
- Material: Aluminum alloy body, CR12MoV piston rod
- Seal material: NBR (Nitrile) seals
- Weight: 0.12kg (0.26lbs)
- Dimensions: 50mm(L) × 18mm(W) × 18mm(H)
- Rod thread: M3 external thread at rod end
- Max theoretical force: 22.6N @0.6MPa (push/pull)
- ISO speed code: 0.1–1.5 m/s
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-compact cylinder designed for space-constrained automation systems. Features a unique embedded flange structure allowing direct mounting in machined cavities. The integrated M3 rod-end thread enables direct tooling attachment without adapters. Optimized for precision positioning in clean environments with IP54 protection against particulate ingress.
- PCB board component insertion machines
- Medical device micro-actuation systems
- Semiconductor wafer handling robots
- Optical lens positioning mechanisms
- 3D printer nozzle control systems
Installation guidelines:
Requires precise cavity machining with H7 tolerance. Use anti-rotation pin (included)
during mounting. Maintain 0.5mm clearance around cylinder body for thermal expansion.
Recommended air supply: ISO 8573-1 Class 2.4.2 (40μm filtration, lubricated).
| Property | Property Value |
|---|---|
| sku | MPEF6X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Cushion Type | Non-cushioned |
| Bore Diameter | <6mm> |
| Stroke | <5mm> |
