Airtac MPEF Embedded Mounting Threaded Cylinder MPEF8X10N
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF Series Embedded Threaded Cylinder MPEF8X10N Specifications
- Model: MPEF8X10N
- Bore size: 8mm
- Stroke: 10mm
- Installation type: Embedded thread (front flange with M5x0.8 threaded holes)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushioning type: Fixed rubber buffer (both ends)
- Port thread: M5x0.8 (standard Rc1/8 adaptor optional)
- Piston rod thread: M5x0.8 external thread
- Seal material: NBR (Nitrile Butadiene Rubber)
- Weight: 0.12kg ±3%
- Dimensions: 50mm(L) × 30mm(W) × 30mm(H)
- Rod end type: Female thread + locknut
- Max theoretical thrust: 50.3N (at 0.63MPa)
- Lubrication: Pre-lubricated (Grease-free operation)
- ISO standard: Compliant with ISO 21287
Ultra-compact embedded cylinder designed for space-constrained automation systems. Features corrosion-resistant aluminum alloy construction with precision-ground rod and integrated mounting threads. The dual-cushion design reduces impact noise by 30% compared to standard models. Operates with filtered dry air (5-40μm filtration recommended).
- Precision semiconductor wafer handling robots
- Medical device assembly lines
- 3D printer filament tensioning mechanisms
- Optical lens positioning systems
- Miniature pneumatic grippers for electronics assembly
Installation note:
Ensure perpendicular mounting surface flatness ≤0.05mm. Use thread-locking compound on mounting screws (M5x0.8, torque ≤1.2N·m). Avoid lateral forces exceeding 5N during operation. For vertical installations, add external guide mechanisms.
| Property | Property Value |
|---|---|
| sku | MPEF8X10N |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Non-threaded |
| Cushion Type | Non-cushioned |
| Bore Diameter | <8mm> |
| Stroke | <10mm> |
