Airtac MPEF Embedded Mounting Threaded Cylinder MPEF8X15N
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF Embedded Threaded Cylinder MPEF8X15N Specifications
- Model: MPEF8X15N
- Type: Single-acting spring return (embedded thread mounting)
- Bore size: 8mm
- Stroke: 15mm
- Operating pressure: 0.05–0.9 MPa
- Port thread: M5×0.8 (pre-installed with integrated threaded holes)
- Piston rod thread: M4×0.7 (external)
- Cushioning: Adjustable rubber buffer
- Mounting type: Embedded screw-in (requires M8×1.25 mounting hole)
- Material: Aluminum alloy body, CR-SEALS®
- Weight: 68g ±2g
- Dimensions: 45mm(L) × 25mm(W) × 25mm(H) (excluding rod extension)
- Temperature range: -10℃ to 80℃
- Lubrication: Pre-lubricated (recommended relube interval: 2,000km)
- Protection rating: IP54 (standard wiper seal)
- Max theoretical force: 4.5N @0.5MPa
Ultra-compact threaded cylinder designed for space-constrained installations requiring precise linear motion. Features integrated mounting threads for direct panel embedding and CR-SEALS® technology for low friction operation. Requires 5μm filtered compressed air with ISO VG32 hydraulic oil mist lubrication.
- Micro-assembly robotic end effectors
- Semiconductor wafer handling systems
- Medical device actuation mechanisms
- Precision clamping fixtures in CNC tooling
- Optical lens positioning stages
Installation note:
Use 0.5-1.0Nm torque for panel mounting. For vertical installations,
position exhaust ports downward to prevent debris accumulation.
Maintain 0.2mm clearance around rod during alignment.
| Property | Property Value |
|---|---|
| sku | MPEF8X15N |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Non-threaded |
| Cushion Type | Non-cushioned |
| Bore Diameter | <8mm> |
| Stroke | <15mm> |
