Airtac MPEF Embedded Mounting Threaded Cylinder MPEF8X5
2、Supports modular integration of multiple cylinders, featuring versatile mounting options to optimize spatial efficiency in installation layouts;
3、No additional mounting accessories required;
4、Multiple bore sizes available to meet diverse application requirements.
Category: Needle Cylinders , Brand: Airtac , Series: MPEF
AirTAC MPEF Flush-mount Threaded Cylinder MPEF8X5 Technical Details
- Model: MPEF8X5
- Type: Single-acting spring return (normally closed)
- Bore size: 8mm
- Stroke: 5mm (Standard), customizable 1-30mm
- Mounting: Threaded body (M8×1.25 embedded installation)
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port size: M5×0.8 (Dual ports)
- Thread type: Metric fine thread
- Piston rod material: Chrome-plated steel (0.5-1.5μm coating)
- Cylinder tube: Aluminum alloy (hard anodized)
- Seal material: NBR (nitrile) with wear-resistant ring
- IP rating: IP40 (Dust protected)
- Weight: 62g ±2g
- Dimensions:
- Body length: 38mm
- Total length (extended): 43mm
- Outer diameter: Φ18mm
- Mounting thread depth: 10mm
Ultra-compact pneumatic cylinder with integrated mounting threads, designed for direct panel embedding in space-constrained automation systems. Features anti-rotation piston design with precision honed tube for smooth operation. The dual-port configuration allows flexible air routing in push/pull applications. Includes magnetic piston version (MPEF8X5-M) for position sensing compatibility.
- Micro-precision clamping in CNC tool changers
- Valve actuation in medical analyzers
- Component ejection in SMT pick-and-place machines
- Lens positioning mechanisms in optical equipment
- Door locking systems in cleanroom environments
Installation guide:
Use 6.5-7.0mm counterbore depth for proper flush mounting.
Apply thread sealant (Loctite 542 recommended) on external threads.
Maximum side load: 2.5N. Lubricate with ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | MPEF8X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Cushion Type | Non-cushioned |
| Bore Diameter | <8mm> |
| Stroke | <5mm> |
