Airtac MSD Multi-Position Fixed Cylinder MSD10X5
The AirTAC Airtac MSD Multi-Position Fixed Cylinder MSD10X5 is a genuine MD multi-mount cylinder (single acting, push type), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 15.8 N of push force at 0.5 MPa. A bumper cushions the impact.
- TypeMulti-mount, single acting, push type
- SeriesMD (standard)
- Bore10 mm
- Push thrust @0.5 MPa15.8 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWithout magnet
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MSD Multi-Position Fixed Cylinder MSD10X5
The MSD10X5 is a single acting, push-type multi-mount cylinder from AirTAC's MD family. Its compact square body fixes from 6 directions - front, back, left, right, top and bottom - so units can be mounted side by side to save space, with magnetic-switch slots around the body and high guide precision. The 10 mm bore gives a theoretical push force of 15.8 N at 0.5 MPa, and the short 5 mm stroke suits very small advances such as seating a pad or tripping a lever. Cushioning is a bumper, the medium is air filtered to 40 um, and speed is 50-500 mm/s.
This is a genuine AirTAC part. MSD is the single acting, push-type variant of the standard MD multi-mount family; the MK family is the no-rotating counterpart if your job needs the rod held from turning. This SKU is shown without a magnet. Operating pressure is 0.2-1.0 MPa (28-145 psi) with an M5x0.8 port and PT thread. We confirm exact dimensions and sizing from the datasheet on request.
Airtac MSD Multi-Position Fixed Cylinder MSD10X5 Technical Specifications
| Model | Airtac MSD Multi-Position Fixed Cylinder MSD10X5 |
|---|---|
| Type | Multi-mount cylinder, single acting, push type |
| Series | MD (standard) |
| Bore | 10 mm |
| Push thrust @0.5 MPa | 15.8 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | Without magnet |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Pick the bore for thrust: this 10 mm bore pushes a theoretical 15.8 N at 0.5 MPa, while the 16, 20, 25 and 32 mm bores give more and the 6 mm bore less. Choose MD if rod rotation is acceptable and MK if it must be prevented. MSD is single acting, push type; double acting, double rod and adjustable-stroke variants are available in the same family. Single acting strokes run up to 20 mm, and this 5 mm stroke fits the family's short-cover design - avoid an over-long stroke. A trailing S on a related SKU adds a magnet; thread is PT by default with G available. Side-load limits come from the datasheet - ask us.
Applications
Small-parts clamping
The 5 mm stroke is enough to seat a pad or lever onto small parts held in a nest, with the 10 mm bore's 15.8 N push at 0.5 MPa suiting light clamping jobs.
Gate stopper on compact conveyors
Bolted through the conveyor frame, the cylinder pushes a stopper pin into the part path; the square body fixes from 6 directions for tidy, side-by-side packing.
Jig positioning pin
Use the short push stroke to advance a locating pin into a jig hole on small assembly fixtures, mounting the body top, side or bottom as the fixture allows.
FAQ
What does MSD10X5 mean?
MSD is AirTAC's single acting, push-type variant of the MD multi-mount cylinder, 10 is the bore in mm and 5 the stroke in mm. No trailing S means this SKU is without a magnet, and the blank thread position means PT; G is available as an option.
Where can I mount this cylinder?
The square body fixes from 6 directions - front, back, left, right, top and bottom - so you can bolt it wherever the machine allows and place units side by side to save space. Cushioning is a bumper; exact dimensions and side-load limits come from the datasheet, which we can confirm for you.
