Airtac MSD Multi-Position Fixed Cylinder MSD16X5
2. Multiple body mounting configurations for simplified installation;
3. Modular stacking capability optimizes spatial efficiency in multi-cylinder arrangements;
4. Integrated high-precision piston rod guidance system operates lubrication-free;
5. Extensive dimensional configurations available for application-specific solutions;
6. Optional high-temperature resistant seals ensure reliable operation at 150°C (Optional feature)
Category: Multi-position Fixed Cylinder , Brand: AIRTAC , Series: MSD
AirTAC MSD16X5 Multi-Position Locking Cylinder Technical Details
- Model: MSD16X5 (Full model: MSD-16X50 where X=Stroke)
- Type: Double-acting with mechanical locking mechanism
- Bore diameter: 16mm (ISO 6432 standard)
- Stroke range: 50mm (Customizable up to 300mm)
- Operating pressure: 0.1–0.8 MPa
- Locking force: 120N max at 0.5MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (Standard), NPT1/8 optional
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Front flange (MF1), rear pivot (MP4), or foot-mounted (MA1)
- Material: Aluminum alloy barrel, hardened stainless steel rod
- Seal type: NBR seals with wear-resistant guide rings
- Weight: 0.28kg (Basic model without accessories)
- Dimensions: 90mm(L) × 30mm(W) × 30mm(H) (At fully retracted position)
- Stroke tolerance: ±1.5mm
- Max piston speed: 500mm/s
- Reed switch compatibility: D-A93 series magnetic sensors
Precision locking cylinder featuring a unique ratchet-and-pawl mechanism for intermediate position holding without continuous air supply. The anodized barrel incorporates dual wiper seals for contaminant exclusion, with chrome-plated rod resisting side loads up to 1.5N·m. Requires 5μm filtered air with ISO VG32 lubricant.
- Rotary index table clamping in CNC automation
- Workpiece staging in semiconductor handlers
- Safety interlocks for robotic welding cells
- Modular fixture systems with position memory
- Vertical lifting mechanisms with fail-safe hold
Installation criticals:
Maintain ≤0.5mm alignment tolerance during mounting. Engage locking pins
before air connection. Cycle 3x at 0.3MPa for mechanism seating. Lubricate
ratchet teeth with silicone grease quarterly.
Avoid applications with high-frequency
vibration (>25Hz) which may cause unintended lock release. For vertical
installations, always use counterbalance valves.
| Property | Property Value |
|---|---|
| sku | MSD16X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <5mm> |
