Airtac MSD Multi-Position Fixed Cylinder MSD20X5
2. Multiple body mounting configurations for simplified installation;
3. Modular stacking capability optimizes spatial efficiency in multi-cylinder arrangements;
4. Integrated high-precision piston rod guidance system operates lubrication-free;
5. Extensive dimensional configurations available for application-specific solutions;
6. Optional high-temperature resistant seals ensure reliable operation at 150°C (Optional feature)
Category: Multi-position Fixed Cylinder , Brand: AIRTAC , Series: MSD
AirTAC MSD Series Multi-Position Locking Cylinder MSD20X5 Technical Specifications
- Model: MSD20X5
- Type: Multi-position locking cylinder (mechanical rod lock)
- Bore size: Ø20mm (±0.1mm tolerance)
- Stroke: 5mm (fixed position locking)
- Operating pressure: 0.05–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion
- Mounting styles: Front flange (MF1), rear flange (MF2), or side mount
- Port size: 1/8" NPT (M5 optional with adapter)
- Temperature range: -10℃ to 80℃ (with NBR seals)
- Material: Aluminum alloy barrel (hard anodized), CR steel piston rod
- Seal material: Nitrile rubber (NBR) standard
- Weight: 420g ±5% (without accessories)
- Dimensions: 136mm(L) × 40mm(W) × 40mm(H) (minimum retracted length)
- Rod thread: M6×1.0 external thread (both ends)
- Position accuracy: ±0.2mm (repeat positioning)
- Maximum locking force: 120N (at 0.5MPa)
Precision multi-station cylinder with mechanical locking mechanism for intermediate position retention. Features dual-action piston with built-in guide bearings for anti-rotation stability. The MSD20X5's chrome-plated piston rod and wear-resistant seals enable 3,000km+ service life under standard conditions (clean air, 1Hz cycle). Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Semiconductor wafer handling robots (position holding during transport)
- Automated test equipment fixture positioning
- Pharmaceutical tablet press tooling height adjustment
- Glass panel polishing machines (multi-stage pressure control)
- Battery assembly line welding jigs
Installation protocol:
Locking mechanism requires 0.3MPa minimum working pressure for reliable engagement.
Lubricate piston rod weekly with ISO VG32 turbine oil when used in high-cycle applications (>2Hz).
Avoid side loads exceeding 15N to prevent guide bearing wear.
| Property | Property Value |
|---|---|
| sku | MSD20X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <5mm> |
