Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X15CA
$18.57
Regular price
$26.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MSI10X15CA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 6432 standard (φ8~25);
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
Installation guidance:
Maximum side load 3N. Use alignment couplers when lateral forces exceed 1N.
For vertical mounting, maintain ≤0.5mm/m parallel alignment tolerance. Lubricate
every 500km travel distance in standard environments.
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI Series Single-Acting Stainless Steel Mini Cylinder MSI10X15CA
- Model: MSI10X15CA
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 15mm
- Operating pressure: 0.15–0.7 MPa
- Temperature range: -20℃ to 80℃
- Port thread: M5x0.8 (standard) / Rc1/8 optional
- Mounting options: Basic front flange (NF) / Foot mounting (TF)
- Seal material: NBR (standard) / FKM available for high-temp
- Cushioning: Adjustable rubber bumper
- Material: SUS304 stainless steel body
- Weight: 0.12kg (excluding accessories)
- Dimensions:
- Body length: 50mm
- Extended length: 65mm (stroke included)
- Width: 20mm (mounting flange)
- Height: 30mm (port center to base)
Ultra-compact corrosion-resistant cylinder designed for precision linear motion in confined spaces. Features non-rotating piston rod (Ø4mm) with chrome plating and IP67 protection rating. Requires 0.1-1μm filtered air with ISO VG32 lubricant (optional oil-free operation).
Ideal Applications:
- Cleanroom automation in semiconductor manufacturing
- Medical device actuation systems
- Food processing equipment (FDA-compliant versions available)
- Precision alignment mechanisms in optical instruments
- Robotic end-effector gripping solutions
Installation guidance:
Maximum side load 3N. Use alignment couplers when lateral forces exceed 1N.
For vertical mounting, maintain ≤0.5mm/m parallel alignment tolerance. Lubricate
every 500km travel distance in standard environments.
| Property | Property Value |
|---|---|
| sku | MSI10X15CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
