Airtac MSI Single Acting Stainless Steel Mini Cylinder MSI10X15U
$18.57
Regular price
$26.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MSI10X15U
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with ISO 6432 standard (φ8~25);
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
Installation note:
Use with guided rail systems for side load protection.
Maximum lateral rod load ≤3N. Lubricate with ISO VG32 turbine oil
if used in continuous high-cycle applications (>1 million strokes).
2. Front/rear covers with fixed cushion rings to minimize cylinder impact during directional changes;
3. Multiple rear cover configurations for enhanced installation flexibility;
4. Riveted enclosure structure securely connects stainless steel cylinder barrel with end covers;
5. Stainless steel piston rod and cylinder barrel enable operation in mildly corrosive environments;
6. Comprehensive selection of cylinder specifications and mounting accessories available.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MSI
AirTAC MSI10X15U Single-Acting Stainless Steel Mini Cylinder Specifications
- Model: MSI10X15U
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 15mm
- Material: Stainless steel (SUS304 barrel, aluminum end caps)
- Operating pressure: 0.1–0.8 MPa
- Port size: M5x0.8 (standard), optional NPT1/8
- Piston speed: 50–800 mm/s
- Seal material: Fluorocarbon rubber (FKM) for high temp / NBR standard
- Temperature range: -20℃ to 150℃ (FKM) / -20℃ to 80℃ (NBR)
- Cushioning: Adjustable rubber bumper
- Weight: 0.12 kg
- Dimensions: 40mm(L) × 25mm(W) × 25mm(H) (excluding rod)
- Rod thread: M5x0.8 female
- Protection rating: IP40 (IP67 with optional rod cover)
- Lubrication: Pre-lubricated (non-replenishing design)
Ultra-compact corrosion-resistant cylinder optimized for precision linear motion in confined spaces. Features non-rotating piston rod (key-guided) for precise positioning. Anti-vibration structure minimizes chatter during high-speed operation. Compatible with clean air or inert gases.
Typical Applications:
- Medical device actuation (sterilization-friendly design)
- Food processing equipment (corrosion-resistant construction)
- Semiconductor wafer handling robots
- Pharmaceutical tablet pressing mechanisms
- Precision optical lens positioning systems
Installation note:
Use with guided rail systems for side load protection.
Maximum lateral rod load ≤3N. Lubricate with ISO VG32 turbine oil
if used in continuous high-cycle applications (>1 million strokes).
| Property | Property Value |
|---|---|
| sku | MSI10X15U |
| Rear Cover Type | Radial Air Inlet |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <15mm> |
