Airtac MSK Multi-position Locking Cylinder MSK20X5
1. Complies with enterprise-standard specifications;
2. Features multiple body mounting configurations for simplified installation and operation;
3. Supports clustered installation of multiple cylinders with space-saving design;
4. High-precision piston rod guidance with maintenance-free lubrication system;
5. Integrated piston rod locking block ensures anti-rotation performance;
6. Comprehensive specifications available for customized pneumatic solutions;
7. Optional high-temperature resistant seals for operational range 0-150°C.
Category: Multi-Position Locking Cylinders | Brand: AirTAC | Series: MSK
AirTAC MSK Series Multi-Position Locking Cylinder MSK20X5 Technical Details
- Model: MSK20X5
- Type: Double-acting multi-position locking cylinder
- Bore size: 20mm
- Stroke: 5mm (Standard), customizable up to 100mm
- Operating pressure: 0.05–0.9 MPa
- Locking mechanism: Dual-piston wedge locking system
- Position holding force: 180N (at 0.5MPa)
- Cushioning type: Adjustable rubber buffer
- Port size: M5x0.8 (Two-position locking variant)
- Mounting style: Side-mounted flange with 4xM5 screws
- Temperature range: -10℃ to 70℃
- Body material: Aluminum alloy (A6063)
- Rod material: Chrome-plated steel (S45C)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.65kg (Dry, without accessories)
- Dimensions: 135mm(L) × 34mm(W) × 42mm(H)
Precision-engineered locking cylinder with integrated mechanical brake, designed for mid-stroke position holding in automation systems. Features dual-position memory capability through independent air circuits (R1/R2 ports). The chrome-plated piston rod resists scoring, while the aluminum body ensures heat dissipation. Requires 5μm filtered air with ISO VG32 turbine oil mist lubrication (0.1-1.0g/m³).
- Rotary index table clamping mechanisms
- PCB drilling machine Z-axis stabilization
- Automated welding fixture positioning
- Glass cutting equipment intermediate stops
- Robotic arm tool changer retention
Operational note:
Engage locking mechanism at ≤0.3MPa pressure differential.
Lubricate every 6 months under normal operation (3 months in high-cycle applications).
Avoid side-load exceeding 30N during extension.
| Property | Property Value |
|---|---|
| sku | MSK20X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <5mm> |
