Airtac MSU Mini Free Mounting Cylinder MSU10X10B
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
AirTAC MSU Miniature Free Mount Cylinder MSU10X10B Specifications
- Model: MSU10X10B
- Type: Double-acting cylinder with free mount design
- Bore size: 10mm
- Stroke: 10mm (adjustable cushion)
- Operating pressure: 0.15–0.8 MPa
- Port thread: M5×0.8 (standard), optional NPT1/8
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Cushion type: Rubber buffer (both ends)
- Rod material: Stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.12kg ±3%
- Dimensions:
- Body diameter: 20mm
- Total length: 54mm (at mid-stroke)
- Mounting hole spacing: 16mm (horizontal) × 16mm (vertical)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (recommended oil viscosity: ISO VG32)
Ultra-compact cylinder optimized for space-critical automation systems, featuring 360° adjustable mounting capability through integrated T-slot design. The dual piston seal structure ensures consistent thrust force (±5% variation) across full pressure range. Includes magnetic piston version (MSU10X10B-M) for position sensing compatibility.
- PCB board handling robots
- Semiconductor wafer sorting equipment
- Dental chair position adjustment mechanisms
- Precision dispensing systems
- Textile machinery thread tension control
Installation note:
Maximum side load capacity 5N. For vertical mounting, use locking nuts on both sides of mounting bracket. Allow 0.5mm clearance for thermal expansion during continuous operation. Lubricate every 500km stroke distance using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | MSU10X10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
