Airtac MSU Mini Free Mounting Cylinder MSU10X4
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
AirTAC MSU Series Miniature Free Mount Cylinder MSU10X4 Technical Details
- Model: MSU10X4 (Metric Series)
- Bore size: Ø10mm
- Stroke: 40mm (Standard range: 10-200mm)
- Operating pressure: 0.05-0.9 MPa
- Operating medium: Dry air (Lubricated or non-lubricated)
- Ambient temperature: -20℃ to 80℃ (No freeze)
- Cushioning: Rubber buffer (Both ends)
- Port size: M5×0.8 (Rc1/8 optional)
- Piston speed: 50-700 mm/s
- Mounting type: Free mount (No specific orientation required)
- Weight: 160g ±5% (Without accessories)
- Dimensions:
- Length: 107mm (Basic length) + stroke
- Width: 28mm (Max. flange width)
- Height: 28mm (Cylinder body diameter)
- Rod thread: M5×0.8 (External)
- Protection class: IP65 (Dust-proof & water jet resistant)
- Material:
- Tube: Aluminum alloy (Hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (Standard), optional Fluorocarbon
Ultra-compact pneumatic cylinder featuring space-saving design with 40% reduced length compared to standard cylinders. The free mounting capability allows 360° orientation flexibility, while the hardened piston rod ensures wear resistance in high-cycle applications. Integrated cushioning mechanism minimizes end-impact noise below 75dB(A). Compatible with ISO 6432 mounting accessories.
- PCB handling robots in electronics manufacturing
- Precision lens positioning in optical equipment
- Micro-dosing valves in pharmaceutical packaging
- Semiconductor wafer transfer mechanisms
- Automated test probe actuation systems
Maintenance advisory:
For non-lubricated operation, use air quality class 4-3-2 per ISO 8573-1.
Relubricate every 3 million cycles using ISO VG32 turbine oil when operated without air lubricator.
| Property | Property Value |
|---|---|
| sku | MSU10X4 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
