Airtac MSU Mini Free Mounting Cylinder MSU10X4B
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
AirTAC MSU10X4B Compact Free Mount Cylinder Specifications
- Model: MSU10X4B (ISO 6432 compliant)
- Type: Double-acting free mount cylinder
- Bore size: 10mm
- Stroke: 4mm (customizable up to 100mm)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Fixed rubber buffer
- Mounting style: Axial mounting holes (M3 thread)
- Port size: M5x0.8 (standard) with optional NPT1/8 adapter
- Temperature range: -10℃ to 80℃
- Cylinder material: Anodized aluminum alloy
- Rod material: Stainless steel SUS304
- Seal material: Heat-resistant polyurethane (NBR optional)
- Weight: 0.22kg (excluding accessories)
- Dimensions: 58mm(L) × 20mm(W) × 20mm(H)
- Stroke tolerance: ±0.5mm
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (non-replenishing design)
Ultra-compact cylinder with space-saving cube-shaped design, featuring integrated mounting bosses for direct panel attachment. The T-slot piston design ensures smooth operation with minimal stick-slip effect. Optimized for precision positioning in clean environments with IP40 protection rating. Requires 5μm filtered air supply.
- Semiconductor wafer handling robots
- Micro-dosing valves in pharmaceutical equipment
- Optical lens positioning systems
- PCB test fixture actuation
- Food packaging portion control gates
Installation note:
Maximum side load capacity 5N. Use floating joints for angular misalignment compensation.
Recommended 0.3-0.5 MPa pressure for high-frequency (>5Hz) operations.
| Property | Property Value |
|---|---|
| sku | MSU10X4B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
