Airtac MSU Mini Free Mounting Cylinder MSU10X6
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
AirTAC MSU Miniature Free Mounting Cylinder MSU10X6 Technical Details
- Series: MSU (Compact ISO Standard Cylinder)
- Bore size: 10mm (0.39")
- Stroke: 6mm (0.24") ±0.5mm tolerance
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Cushioning: Elastic rubber buffer (adjustable end caps)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Port size: M5×0.8 (Dual auto switch grooves standard)
- Piston rod material: Chrome-plated steel (SUS304 optional)
- Tube material: Anodized aluminum alloy
- Seal type: NBR seals (FKM/Viton available for high temp)
- Weight: 0.23kg (0.51lb) ±3%
- Dimensions: 50mm(L) × 22mm(W) × 22mm(H) (Body only)
- Full length (extended): 68mm (2.68")
- Repeat accuracy: ±0.1mm
- Max theoretical thrust: 7.1N @0.5MPa (72kgf/cm²)
- ISO standard: 6432 (8mm-25mm bore series)
Ultra-compact cylinder with 360° free mounting capability via integrated T-slot design. Features dual magnet positions for sensor mounting and self-lubricating bushings for maintenance-free operation. Optimized for high-frequency cycles (up to 5Hz) with 0.1mm/s minimum speed control. Includes anti-rotation mechanism for precise linear motion.
- PCB component insertion machines
- Pharmaceutical blister packaging systems
- Micro-drilling equipment positioning
- Lens polishing mechanism actuators
- 3D printer filament feed control
- Laboratory sample handling robots
Installation tip:
Use M3 mounting screws with 0.4-0.6Nm torque. For vertical mounting,
maintain 0.3mm clearance between rod end and load. Lubricate with
ISO VG32 hydraulic oil if operating below -10℃.
- MSU-M10N2: Compact magnetic sensor
- AKS1A: Miniature speed controller
- MSU-BK: Anti-vibration mounting bracket kit
| Property | Property Value |
|---|---|
| sku | MSU10X6 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M3×0.5 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <6mm> |
