Airtac MSU Mini Free Mounting Cylinder MSU12X10B
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
AirTAC MSU12X10B Miniature Free Mount Cylinder Specifications
- Model: MSU12X10B
- Bore size: 12mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Adjustable cushioning (both ends)
- Mounting style: Free mount type (requires separate bracket)
- Port size: M5x0.8
- Piston rod thread: M6x1 external thread
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- End caps: Aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seals: NBR rubber
- Weight: 0.25kg (excluding accessories)
- Dimensions:
- Total length: 48mm (at mid-stroke position)
- Width: 24mm (including ports)
- Height: 24mm (barrel diameter)
- Protection class: IP40 (standard)
- Max theoretical thrust: 8.7N @0.5MPa
A space-saving pneumatic actuator with precision-machined components, featuring dual adjustable cushions for smooth stroke termination. The hard-anodized barrel provides superior wear resistance, while the stainless steel piston rod ensures corrosion protection in humid environments. Requires filtered dry air (40μm filtration, dew point -20℃ below ambient).
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in medical analyzers
- Precision clamping in watch assembly
- Sorting gates in small parcel logistics systems
- Lens positioning in optical equipment
Installation guidelines:
Use floating joints to compensate for misalignment (max ±0.5° angular deviation).
Lubricate with ISO VG32 hydraulic oil if operating below 1 cycle/minute.
For vertical mounting, add 10% safety factor to thrust calculations.
| Property | Property Value |
|---|---|
| sku | MSU12X10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
