Airtac MSU Mini Free Mounting Cylinder MSU16X5
2. Features four-way mounting capability for flexible installation;
3. Space-efficient design allows multiple cylinders to be grouped in parallel configurations;
4. Integrated front guiding boss ensures precise alignment and reliable positioning;
5. Precision-honed bore with hard anodized treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic version enables position sensing functionality;
7. Pre-machined T-slots on barrel facilitate versatile magnetic sensor mounting;
8. Asymmetrical bidirectional piston sealing system with compact dimensions and integrated oil reservoir design.
Category: Free Mount Cylinder | Brand: AIRTAC | Series: MSU
AirTAC MSU16X5 Compact Free Mount Cylinder Specifications
- Model: MSU16X5
- Bore size: 16mm
- Stroke: 5mm (Standard)
- Operating pressure: 0.05–0.9 MPa
- Max thrust: 17.6N @0.5MPa
- Ambient temperature: -20℃ to 80℃
- Cushion type: Rubber buffer
- Mounting style: Free installation (Side/end mounting via optional brackets)
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel
- Seal type: NBR/PU seals (Oil-resistant)
- Weight: 0.25kg (Body only)
- Dimensions: 55mm(L) × 32mm(W) × 32mm(H) (Min. retracted length)
- Stroke tolerance: ±0.5mm
- Max speed: 500mm/s
- ISO standard: 6432 (Compact cylinder specifications)
Ultra-compact cylinder designed for space-constrained automation systems. Features a space-saving 75% reduction in length compared to standard cylinders, with dual-purpose mounting grooves allowing direct clamp installation without brackets. Precision honed tube ensures <1μm surface roughness for smooth operation.
- PCB handling robots in electronics manufacturing
- Precision lens positioning in optical equipment
- Micro-dosing valves in medical devices
- Semiconductor wafer clamping systems
- High-speed sorting gates in packaging lines
Installation note:
Maintain 0.5mm clearance between rod end and load during alignment.
Use only JIS B2353 hydraulic oil for lubrication. Avoid lateral
force exceeding 1.5N·m. For vertical mounting, install rod-down
orientation preferred.
- MSU-MK16: Side mounting kit with vibration-damping pads
- MSU-RS16: Rod-end magnetic sensor slot adapter
- MSU-EC5: 5mm stroke extension collar set
| Property | Property Value |
|---|---|
| sku | MSU16X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <5mm> |
