Airtac MSUR Compact Free Mounting Cylinder MSUR12X10
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR12X10 Compact Free Mount Cylinder Specifications
- Model: MSUR12X10
- Type: Single rod double-acting cylinder
- Bore size: 12mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Cushioning: Adjustable rubber buffer
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (Nitrile)
- Rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (hard anodized)
- Weight: 0.15 kg (unlubricated)
- Dimensions: 60mm(L) × 25mm(W) × 25mm(H) (Stroke extended)
- Mounting type: Free position (no fixed pattern)
- ISO standard: 6432 (Compact series)
- Position detection: Built-in magnet (D-M9N sensor compatible)
Ultra-compact pneumatic cylinder featuring space-saving design with 50% reduced length compared to standard ISO cylinders. Precision-machined guide bushing ensures smooth linear motion and minimal lateral play. Pre-lubricated for maintenance-free operation (relubrication interval: 2,000km travel distance).
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical equipment
- Precision clamping devices for CNC tooling
- Automated test probe positioning systems
- Compact packaging machine actuators
Installation guidelines:
For optimal performance, maintain 0.5mm minimum clearance between mounting surfaces.
Use dynamic load calculations when stroke exceeds 50mm. Lubricate with ISO VG32 turbine oil
if operating below -10℃. Avoid side load exceeding 2N·m.
| Property | Property Value |
|---|---|
| sku | MSUR12X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
