Airtac MSUR Compact Free Mounting Cylinder MSUR12X10S
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Cylinder MSUR12X10S Technical Details
- Model: MSUR12X10S
- Bore size: 12mm
- Stroke: 10mm
- Operation type: Double-acting
- Operating pressure: 0.05–0.9 MPa
- Ambient temperature: -10℃ to 60℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5×0.8 (Rc1/8/NPT1/8 optional)
- Piston speed: 50–700 mm/s
- Mounting type: Free mount (side flange/basic type)
- Rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR + PU combination
- Weight: 0.25kg ±5%
- Dimensions:
- Body length: 58mm
- Stroke length: 10mm
- Total length (extended): 68mm
- Width: 25mm
- Height: 25mm
- Rod thread: M5×0.8 (male)
- Protection class: IP54 (standard)
- ISO standard: 6432 (compatible)
Ultra-compact cylinder with space-saving design featuring 40% reduced length compared to standard ISO cylinders. Precision-engineered with dual sealing system (dust-proof + pressure seals) for maintenance-free operation. Integrated mounting grooves allow direct installation without separate brackets. Optional magnetic piston version (MSUR12X10S-M) available for position sensing.
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Automatic door locking systems
- Semiconductor wafer processing equipment
- Precision dosing valves in food packaging
- 3D printer nozzle control systems
Maintenance tip:
Lubricate with ISO VG32 hydraulic oil (non-detergent) every 500,000 cycles.
Avoid side load exceeding 1.5N·m. For vertical mounting, use counterbalance valves.
| Property | Property Value |
|---|---|
| sku | MSUR12X10S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
