Airtac MSUR Compact Free Mounting Cylinder MSUR12X5S
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Cylinder MSUR12X5S Technical Details
- Model: MSUR12X5S
- Bore size: 12mm (standard series)
- Stroke: 5mm (customizable up to 100mm)
- Operating pressure: 0.15–0.8 MPa
- Cushion type: Fixed rubber bumper (both ends)
- Mounting style: Free installation (no specific orientation required)
- Port size: M5x0.8 (standard) with Rc1/8/NPT1/8 adapters optional
- Temperature range: -20℃ to 80℃
- Piston material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Seal type: NBR seals (fluorocarbon optional)
- Weight: 0.15kg ±5% (excluding accessories)
- Dimensions: 50mm(L) × 20mm(W) × 20mm(H) (minimum retracted length)
- Protection class: IP40 (dust resistant)
- Max speed: 500mm/s (with cushion adjustment)
Ultra-compact cylinder featuring space-saving design with 6.5mm shorter body length than standard models. Precision-ground piston rod with anti-rotation mechanism ensures stable linear motion. Integrated mounting slots allow 360° flexible installation without additional brackets. Low friction design requires minimal lubrication (relubrication every 2000km travel).
- PCB handling robots in electronics manufacturing
- Micro-pneumatic grippers for watch assembly
- Dental chair positioning mechanisms
- Semiconductor wafer transfer systems
- Precision dispensing equipment valves
Installation note:
Maintain 0.5mm minimum clearance between cylinder body and mounting surface for thermal expansion.
Use only non-hardening thread lockers (Loctite 243 recommended) for mounting screws.
Maintenance alert:
When used in vertical downward thrust applications, install an external check valve to prevent free fall during pressure loss.
| Property | Property Value |
|---|---|
| sku | MSUR12X5S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
