Airtac MSUR Compact Free Mounting Cylinder MSUR16X10S
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Cylinder MSUR16X10S Specifications
- Model: MSUR16X10S
- Type: Double-acting, free mount cylinder
- Bore size: 16mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Cushioning: Rubber buffer (adjustable at both ends)
- Port size: 1/8" NPT (M5 optional)
- Ambient temperature: -20℃ to +80℃
- Seal material: NBR (Nitrile), optional FKM (Fluorocarbon)
- Piston speed: 50–800 mm/s (lubricated)
- Mounting style: Side/Base mounting with 4x M3 threaded holes
- Body material: Aluminum alloy (anodized finish)
- Weight: 0.18kg (without accessories)
- Dimensions: 80mm(L) × 34mm(W) × 25mm(H)
- Protection rating: IP65 (standard wiper seal)
- Repeat accuracy: ±0.2mm
Ultra-compact cylinder designed for space-constrained automation systems, featuring a rectangular body for secure mounting in tight spaces. The through-hole piston rod design enhances lateral load capacity (max 2.5N·m). Includes built-in magnet for sensor mounting (ISO 21287 compliant). Requires 5μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
- PCB handling robots in electronics assembly
- Medical device positioning mechanisms
- Conveyor gate actuators in packaging lines
- Precision clamping fixtures for CNC machines
- Laboratory sample handling systems
Installation note:
Maximum side load ≤10% of thrust rating. For vertical mounting,
use counterbalance valves when handling suspended loads.
Lubricate every 3 months under normal operation (500km stroke cycle).
- MSQ-M9NW magnetic sensor (2-wire)
- MSUB-6D adjustable mounting bracket
- ASL6-01 rod lock kit
- Heat-resistant seals (+120℃ version)
| Property | Property Value |
|---|---|
| sku | MSUR16X10S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
