Airtac MSUR Compact Free Mounting Cylinder MSUR16X10SB
$30.00
Regular price
$37.50
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MSUR16X10SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use counterbalance valves for load holding.
Avoid side loads exceeding 2N·m torque. Lubricate every 5 million cycles.
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Cylinder MSUR16X10SB Technical Details
- Model: MSUR16X10SB
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 10mm ±0.5mm
- Operation type: Single-rod double-acting
- Working pressure range: 0.05-1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable elastic cushion (both ends)
- Port size: M5x0.8 (standard) with 1/8" NPT adaptor optional
- Piston material: Aluminum alloy (anodized surface)
- Rod material: Stainless steel SUS304
- Seal type: NBR rubber (FDA compliant option available)
- Weight: 0.18kg ±5% (without accessories)
- Dimensions (L×W×H):
- Basic length: 70mm (excluding rod protrusion)
- Rod extension: +10mm stroke length
- Mounting base: 16mm(W) × 25mm(H)
- Repeat positioning accuracy: ±0.1mm
- Max theoretical thrust: 20.1N at 0.63MPa
- Lubrication: Pre-lubricated (Use ISO VG32 hydraulic oil if re-lubing)
Ultra-compact cylinder with space-saving design featuring 360° adjustable mounting points. The MSUR16X10SB combines a chrome-plated piston rod with corrosion-resistant aluminum body, achieving 2,000km service life under standard conditions. Includes built-in magnet for position sensing compatibility (sensor sold separately).
Ideal for:
- High-density automation cells in semiconductor manufacturing
- Precision clamping mechanisms in CNC tool changers
- Medical device actuation systems requiring FDA-compliant materials
- Collaborative robot end-effector positioning
- Packaging line divert arm operations
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use counterbalance valves for load holding.
Avoid side loads exceeding 2N·m torque. Lubricate every 5 million cycles.
Common accessories:
- MSQ-M8N proximity sensor (2-wire DC type)
- AMF-04 speed controller with needle valve
- MFH-6-16C reinforced mounting bracket
- Special tool kit (STK-MSR) for cushion adjustment
| Property | Property Value |
|---|---|
| sku | MSUR16X10SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
