Airtac MSUR Compact Free Mounting Cylinder MSUR16X5
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Free Mount Cylinder MSUR16X5 Technical Details
- Model designation: MSUR16X5
- Bore size: 16mm (ISO 6432 standard)
- Stroke: 5mm (±0.5mm tolerance)
- Operating pressure: 0.1-0.9 MPa
- Port thread: M5x0.8 (dual mounting positions)
- Cushioning type: Adjustable rubber buffer
- Piston speed: 50-800 mm/s (lubricated condition)
- Ambient temperature: -10℃ to 70℃
- Material composition:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- Seals: NBR (nitrile butadiene rubber)
- Weight: 0.12kg (excluding accessories)
- Compact dimensions:
- Body diameter: Φ16mm
- Total length (L): 52mm (at retracted position)
- Mounting base: 20mm × 16mm
- Rod end thread: M4×0.7 (female)
- ISO certification: Compliant with ISO 6432:2015
Ultra-compact cylinder designed for space-constrained automation systems requiring precise linear motion. Features 360° adjustable mounting slots and dual anti-rotation guides for flexible installation. Optimized for low friction operation with self-lubricating guide bushings. Includes magnetic piston for position sensing compatibility (sensor not included).
- PCB handling robots in electronics manufacturing
- Micro-dosing mechanisms in medical analyzers
- Precision clamping in watchmaking jigs
- Paper feed mechanisms in compact printers
- Valve actuation in portable gas analyzers
Installation protocol:
Apply ISO VG32 hydraulic oil for initial lubrication.
Maintain 0.5mm minimum clearance between magnetic sensor
and cylinder body when using position detection.
Torque limit for mounting screws: 0.8N·m max.
| Property | Property Value |
|---|---|
| sku | MSUR16X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <5mm> |
