Airtac MSUR Compact Free Mounting Cylinder MSUR20X10
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Free Mount Cylinder MSUR20X10 Specifications
- Model: MSUR20X10
- Bore size: 20mm (0.787")
- Stroke: 10mm (0.394")
- Operating pressure: 0.05-0.9 MPa (7-130 psi)
- Operating temperature: -10℃ to 70℃ (14°F to 158°F)
- Cushion type: Fixed rubber buffer
- Port size: M5x0.8 (UNF #10-32 optional)
- Piston speed: 50-750 mm/s
- Mounting type: Free position (no specific orientation required)
- Rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR (Nitrile rubber)
- Weight: 0.23 kg (0.51 lbs)
- Dimensions (L×W×H): 80mm (3.15") body length × 28mm (1.10") width × 28mm (1.10") height (excluding rod)
Ultra-compact double-acting cylinder featuring patented auto-alignment technology for vibration-resistant operation. The tapered piston design achieves 98% mechanical efficiency with minimal air consumption. Integrated wear-resistant guides enable omnidirectional mounting without performance degradation. Compatible with ISO 6432 mounting accessories.
- PCB handling robots in electronics assembly
- Precision lens positioning in optical equipment
- Micro-dosing valves in pharmaceutical packaging
- Semiconductor wafer clamping mechanisms
- Automated test probe positioning systems
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between rod end and workpiece.
For vertical installations exceeding 45° angle, use auxiliary guide rails (sold separately).
| Property | Property Value |
|---|---|
| sku | MSUR20X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
