Airtac MSUR Compact Free Mounting Cylinder MSUR20X5B
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Cylinder MSUR20X5B Specifications
- Model: MSUR20X5B
- Type: Double-acting free mount cylinder
- Bore size: 20mm
- Stroke: 5mm (standard)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Rubber buffer (both ends)
- Port size: M5x0.8 (dual ports)
- Mounting style: Front flange/Foot/Threaded through-hole
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR
- Weight: ~0.25kg
- Dimensions (L×W×H): 98mm × 40mm × 40mm (including rod extension)
- Rod thread: M5x0.8 (external)
- Max theoretical thrust: 63N @0.5MPa
- Piston speed: 50–700mm/s
Ultra-compact pneumatic cylinder designed for space-constrained automation systems. Features multiple mounting options (ISO 15552 accessory compatibility) and dual-position sensing slots for magnetic switch installation. The anodized body resists corrosion in humid environments while maintaining precise linear motion.
- PCB handling robots in electronics assembly
- Micro-part positioning in watch manufacturing
- Medical device actuation mechanisms
- Precision clamping in optical lens production
- Automated test equipment sample handling
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 2N·m.
For vertical mounting, use locknuts on piston rod threads. Allow 5mm clearance for rod extension.
| Property | Property Value |
|---|---|
| sku | MSUR20X5B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <5mm> |
