Airtac MSUR Compact Free Mounting Cylinder MSUR20X5S
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Free Mount Cylinder MSUR20X5S Specifications
- Model: MSUR20X5S
- Bore size: 20mm
- Stroke: 50mm (standard, customizable 5-300mm)
- Operating pressure: 0.05-1.0 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: Fixed rubber buffer + adjustable air cushion
- Port size: M5x0.8 (dual ports for front/rear operation)
- Piston speed: 50-750 mm/s
- Mounting type: Free position (through-hole screw mounting)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.48kg (with rod)
- Dimensions:
- Body length: 103mm
- Width: 34mm (mounting face)
- Height: 34mm (excluding rod)
- Rod extension: +50mm (total length 153mm at full stroke)
- ISO standard: Compliant with ISO 6432
- Protection rating: IP54 (standard), IP67 optional
Ultra-compact cylinder featuring dual cushioning system and anti-rotation rod design. The MSUR20X5S's symmetrical mounting grooves enable 360° orientation flexibility in space-constrained installations. Precision honed tube ensures ≤0.5μm surface roughness for smooth operation. Pre-lubricated for maintenance-free service (relubrication interval: 2,000km stroke distance).
- PCB handling robots in electronics manufacturing
- Dispenser nozzle positioning in packaging lines
- Micro-part clamping in watchmaking/jewelry assembly
- Laboratory automation equipment
- Medical device actuation systems
- Cleanroom-compatible machinery
Installation tip:
Use M4x8mm mounting screws (max torque 1.2N·m). For vertical mounting,
add 0.05MPa extra pressure to compensate for self-weight. Avoid side
load exceeding 15N to prevent rod deflection.
| Property | Property Value |
|---|---|
| sku | MSUR20X5S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <5mm> |
