Airtac MTD Multi-position Locking Cylinder MTD10X10S
The AirTAC MTD Multi-position Locking Cylinder MTD10X10S is a genuine MD multi-mount cylinder (single acting, pull type), 10 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 9.5 N of pull force at 0.5 MPa. A bumper cushions the impact.
- TypeMulti-mount, single acting, pull type
- SeriesMD (standard)
- Bore10 mm
- Pull thrust @0.5 MPa9.5 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MTD Multi-position Locking Cylinder MTD10X10S
MTD10X10S is a 10 mm bore, 10 mm stroke single-acting pull type cylinder from AirTAC's MD multi-mount series, with a magnet as the trailing S in the code shows. The compact square body fixes from six directions - front, back, left, right, top and bottom - so units mount side by side to save space, and the slots around the body take magnetic switches. Air works in one stroke only, with a speed range of 50-500 mm/s; the cushion is a bumper, the medium is air filtered to 40 um, proof pressure is 1.5 MPa (215 psi) and operating pressure is 0.2-1.0 MPa (28-145 psi). Confirm the pull-side thrust figure for this bore from the datasheet before sizing.
This is a genuine AirTAC part. In the family, MD is the standard series while MK is the no-rotating version with a fixed rod and plate; MTD marks the single-acting pull type. This SKU carries a magnet, with an M5x0.8 port and PT thread as standard. Typical materials are aluminium alloy body and covers, a stainless or S45C rod and NBR seals - bore-specific details, dimensions and sensor selection come from the datasheet, which we confirm on request.
Airtac MTD Multi-position Locking Cylinder MTD10X10S Technical Specifications
| Model | Airtac MTD Multi-position Locking Cylinder MTD10X10S |
|---|---|
| Type | Multi-mount cylinder, single acting, pull type |
| Series | MD (standard) |
| Bore | 10 mm |
| Pull thrust @0.5 MPa | 9.5 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Bore sets the force available; for this single-acting pull type, take the exact pull-side thrust figure from the datasheet rather than quoting push-side numbers. Choose MD if rod rotation is acceptable and MK if the rod must not turn; MTD is single-acting pull, where air drives one stroke only. Strokes for single-acting cylinders run up to 20 mm, so 10 mm fits the table - keep the stroke short, as the covers suit compact duty. The trailing S means this SKU includes a magnet for switch sensing; a code without S would be magnet-free. Pick PT (blank) or G port thread.
Applications
Position check pin
Retracts a check pin under air so a positioned part can move on, with the magnet in the piston feeding switch feedback from the body slots. Six-way fixing suits cramped fixtures.
Fail-safe release stopper
Holds a small part back at a station and retracts under air to release it; when air is vented the pin returns. The bumper cushions the stop, and side-by-side mounting saves rail space.
Jig indexing pin
Pulls the indexing pin clear of the jig on air so the pallet can advance, then re-engages when air is released. The magnet gives a signal that the pin is retracted.
FAQ
What does the S at the end of MTD10X10S mean?
The trailing S means this cylinder is supplied with a magnet in the piston, so magnetic switches can be sensed in the slots around the body. A code without the S would be the same cylinder without a magnet. The rest of the code decodes as: MTD single-acting pull type, 10 mm bore, 10 mm stroke, PT thread.
How is this cylinder mounted on my fixture?
The square body can be fixed from six directions - front, back, left, right, top and bottom - so several units can be mounted side by side to save space. Keep strokes short to suit the compact covers; single-acting strokes run up to 20 mm. Exact dimensions and side-load allowances come from the datasheet - we confirm on request.
