Airtac MTD Multi-position Locking Cylinder MTD16X20S
The AirTAC Airtac MTD Multi-position Locking Cylinder MTD16X20S is a genuine MD multi-mount cylinder (single acting, pull type), 16 mm bore. Its compact square body fixes from six directions and mounts side by side to save space. It delivers about 60.5 N of pull force at 0.5 MPa. A bumper cushions the impact.
- TypeMulti-mount, single acting, pull type
- SeriesMD (standard)
- Bore16 mm
- Pull thrust @0.5 MPa60.5 N
- Operating pressure0.2 - 1.0 MPa (28 - 145 psi)
- Port sizeM5x0.8
- CushionBumper
- MagnetWith magnet (sensor-ready)
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MTD Multi-position Locking Cylinder MTD16X20S
The MTD16X20S is an AirTAC multi-mount cylinder: a compact square-body actuator that fixes from six directions - front, back, left, right, top and bottom - so several units can be mounted side by side to save space. Magnetic-switch slots run around the body. This unit is the MTD variant, single acting, pull type: applied air pulls the rod in and the spring extends it when air is removed, giving a natural fail-out action. The trailing S in the code means this SKU carries a magnet for position sensing. The bore 16 x 20 mm stroke suits short-reach pull-in work; it runs on filtered air (40 um) at 0.2-1.0 MPa (28-145 psi) at 50-500 mm/s with a bumper for cushioning. Theoretical pull force for bore 16 is listed in the datasheet; the push side of a single-acting cylinder always gives more force than the pull side.
This is a genuine AirTAC part from the standard MD family; the MK family is the no-rotating version with an anti-rotation plate if rod rotation must be prevented. This SKU is shown WITH a magnet (the S) and PT thread by default, with G selectable. We confirm dimensions, weights and sizing details from the datasheet on request.
Airtac MTD Multi-position Locking Cylinder MTD16X20S Technical Specifications
| Model | Airtac MTD Multi-position Locking Cylinder MTD16X20S |
|---|---|
| Type | Multi-mount cylinder, single acting, pull type |
| Series | MD (standard) |
| Bore | 16 mm |
| Pull thrust @0.5 MPa | 60.5 N |
| Port size | M5x0.8 (PT thread) |
| Magnet | With magnet (S) |
| Fluid | Air, filtered to 40 um |
|---|---|
| Operating pressure | 0.2 - 1.0 MPa (28 - 145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to 70 C |
| Speed range | 50 - 500 mm/s |
| Cushion | Bumper |
| Mounting | Fix from 6 directions; mountable side by side |
Specifications follow the official AirTAC MD/MK multi-mount data. The front cover and piston are short, so avoid an over-long stroke. An optional high-temperature seal material extends the range to 0 to 150 C. Overall dimensions vary per stroke and allowable side-load is published as curves — ask us and we confirm from the datasheet.
How to choose
Select the bore for thrust: bore 16 delivers its rated single-acting pull force at 0.5 MPa per the datasheet, and since the push side always exceeds the pull side on single-acting cylinders, choose pull type (MTD/MTK) where spring-out, air-in action is wanted. Decide MD (rod rotation allowed) versus MK (no-rotating) first. Acting options are double, single push, single pull, double rod or adjustable stroke. Single-acting strokes stop at 20 mm, so this 20 mm stroke is already the maximum - short covers will not allow an over-long stroke, so check any non-standard length with us. The magnet is optional and ordered via the trailing S, which this SKU has; port thread is PT by default with G available. Side-load figures and exact dimensions come from the datasheet - just ask.
Applications
Spring-out press-lite seat check on a small fixture
The spring keeps the plunger out so the operator always sees go/no-go position, and air pulls it back to clear the part. The magnet drives a switch to confirm retraction, and six-way fixing lets the body sit flush inside the fixture plate.
Sensor-verified divert stopper between conveyor lanes
Normally extended by its spring, the rod blocks small packages at a junction; air pulls it in to divert flow. The magnet allows a retracted-position signal for PLC interlocking, and side-by-side mounting stacks multiple stoppers on one rail.
Indexing pin with position feedback on a dial table
Spring extends the pin into the index plate; air retracts it for rotation. The magnet confirms pin-in/pin-out to the controller, the compact square body fits the shallow table skirt, and the 20 mm stroke matches typical index-plate pocket depth.
FAQ
What does the S at the end of MTD16X20S mean?
The trailing S means this cylinder is supplied WITH a built-in magnet, so magnetic switches can be clipped into the slots around the body for position sensing. The same cylinder without an S in the code is supplied without a magnet - the magnet is an option on the MD/MK range, not a standard feature, so order the S version if you need switch feedback. Thread is PT on this SKU; G is selectable at order time.
Is 20 mm really the longest stroke for this single-acting pull cylinder?
Yes. Single-acting MTD variants are offered only up to 20 mm stroke, so the 20 mm on this SKU is at the maximum - the short covers do not permit an over-long stroke. If your job needs more travel, step up to a double-acting MD or MK unit, or an MDJ/MKJ model that adds a 10/20/30 mm adjustable range. Exact body dimensions for the chosen stroke are in the datasheet; we can confirm them for you.
