Airtac MTD Multi-position Locking Cylinder MTD25X10
2. Multiple mounting configurations with integral body design for simplified installation;
3. Modular design allows parallel cylinder arrangement, optimizing space utilization;
4. Precision-guided piston rod with self-lubricating system eliminates external lubrication requirements;
5. Comprehensive model range with standardized specifications for flexible application matching;
6. Optional high-temperature seals ensure reliable performance at 150°C operating conditions. (Optional feature)
Category: Multi-position Fixed Cylinders , Brand: AirTAC , Series: MTD
AirTAC MTD25X10 Multi-Position Locking Cylinder Specifications
- Model: MTD25X10
- Type: Double-acting multi-position lock cylinder
- Bore size: Ø25mm
- Stroke: 10mm (±1mm)
- Operating pressure: 0.05–1.0 MPa
- Locking positions: 3 preset positions (adjustable)
- Port size: M5×0.8 (G1/8 adaptor included)
- Piston speed: 50–800 mm/s
- Locking force: 220N (at 0.5 MPa)
- Repeat positioning accuracy: ±0.1mm
- Temperature range: -10℃ to 80℃
- Seal material: Polyurethane (PU) + Nitrile rubber (NBR)
- Body material: Anodized aluminum alloy
- Weight: 650g ±5%
- Dimensions: 156mm(L) × 45mm(W) × 45mm(H)
- Mounting type: Standard front flange with 4×M5 threaded holes
- Protection rating: IP54 (standard), IP67 (optional)
- Cushioning: Adjustable pneumatic cushioning at both ends
Precision multi-station locking cylinder with mechanical position memory function, featuring dual-position magnetic sensing slots for automated position feedback. The hardened stainless steel guide rod ensures wear resistance during frequent position changes. Requires 5μm filtered compressed air and regular lubrication (ISO VG32 recommended).
- Rotary indexing table positioning in assembly machines
- Tool changing mechanisms in CNC automation
- Precision clamping in semiconductor wafer handling
- Multi-stage height adjustment in inspection equipment
- Position locking in robotic end-effector systems
Installation note:
Maintain perpendicular alignment within 0.2mm/m tolerance. For vertical mounting,
use the auxiliary support bracket (ASB-25 accessory recommended). Lubricate
guide rod weekly under continuous operation.
| Property | Property Value |
|---|---|
| sku | MTD25X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <25 mm> |
| Stroke | <10mm> |
