Airtac MTI Single Acting Stainless Steel Mini Cylinder MTI10X10CA
2. Integrated fixed cushion rings on front/rear covers minimize impact during directional changes;
3. Multiple rear cover configurations facilitate easier installation;
4. Crimped structure between stainless steel cylinder body and end covers ensures secure connection;
5. Stainless steel construction (piston rod & cylinder body) ensures resistance to moderately corrosive environments;
6. Comprehensive cylinder specifications and mounting accessories available, offering versatility for diverse application needs.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MTI Single-Action Stainless Steel Mini Cylinders
AirTAC MTI Single-Acting Stainless Steel Mini Cylinder MTI10X10CA Specifications
- Model: MTI10X10CA
- Type: Single-acting (spring return)
- Bore size: 10mm
- Stroke: 10mm
- Operating pressure: 0.05–0.7 MPa
- Operating temperature: -10℃ to 80℃
- Port size: M5x0.8 (standard) with 6mm push-in fitting
- Mounting style: Standard radial mounting holes (2x ø4.5mm)
- Cylinder body material: Stainless steel (SUS304)
- Piston rod material: Stainless steel (SUS304) with hard chrome plating
- Cushioning: Adjustable rubber buffer
- Seal material: NBR (nitrile rubber) with wear-resistant design
- Protection rating: IP54 (standard wiper seal)
- Weight: 0.12kg (excluding accessories)
- Dimensions:
- Extended length: 62mm
- Retracted length: 52mm
- Body diameter: 20mm
- Mounting bracket width: 16mm
Ultra-compact stainless steel cylinder designed for precision linear motion in confined spaces. Features corrosion-resistant construction with medical-grade surface finish (Ra≤0.8μm), making it ideal for clean environments. The spring-return mechanism provides reliable retraction force (3.2N at 0.5MPa). Includes built-in auto-adjust cushioning to minimize end-impact noise below 65dB.
- Medical device actuation systems
- Food processing equipment (FDA-compliant lubrication)
- Laboratory automation sample handling
- Semiconductor wafer positioning
- Cleanroom robotic arms (ISO Class 5 environments)
Installation recommendations:1. Use 5-40μm filtered dry air with ISO VG32 hydraulic oil mist lubrication
2. Maintain 0.5mm minimum lateral clearance during alignment
3. Cycle rate should not exceed 120 cycles/minute for optimal seal life
4. For vertical mounting, install with piston rod facing downward to prevent debris accumulation
| Property | Property Value |
|---|---|
| sku | MTI10X10CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <10mm> |
