Airtac MUR Compact Free Mount Cylinder MUR12X10
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Cylinder MUR12X10 Technical Details
- Model: MUR12X10
- Bore size: 12mm
- Stroke: 10mm (Customizable 5-100mm)
- Operating pressure: 0.05-0.9 MPa
- Cushioning: Rubber buffer + adjustable pneumatic cushion
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Piston speed: 50-700 mm/s
- Ambient temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (Nitrile rubber)
- Weight: 0.18 kg (Without accessories)
- Dimensions:
- Length: 78mm (Basic length) + stroke
- Width: 24mm (Body diameter)
- Height: 24mm (Body diameter)
- Protection class: IP65 (Dust-tight & water jet protected)
- Mounting options: Axial mounting holes (M3 thread)
Ultra-compact round cylinder with space-saving design, featuring 360° adjustable mounting points through axial through-holes. The double-acting design provides precise linear motion control with low friction resistance. Anti-rotation structure ensures stable operation in high-cycle applications. Compatible with ISO 6432 standards for easy system integration.
- Precision positioning in semiconductor handling robots
- Clamping mechanisms in PCB assembly equipment
- Valve actuation in medical analyzers
- Component ejection in micro-molding machines
- Camera module alignment in optical inspection systems
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between rod end and load.
For vertical mounting, use speed controller to prevent piston slam.
| Property | Property Value |
|---|---|
| sku | MUR12X10 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
