Airtac MUR Compact Free Mount Cylinder MUR12X15B
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR12X15B Compact Free Mounting Cylinder Specifications
- Model: MUR12X15B
- Bore size: 12mm (0.47")
- Stroke: 15mm (0.59")
- Mounting type: Free position (universal mounting capability)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Piston speed: 50–800 mm/s (with cushioning)
- Cushioning: Adjustable pneumatic cushion
- Port size: M5x0.8 (Rc1/8" optional)
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR/PU (nitrile/polyurethane)
- Weight: 0.22 kg (0.485 lbs)
- Dimensions:
- Total length (retracted): 67mm (2.64")
- Body diameter: 20mm (0.79")
- Mounting base: 30mm x 30mm (1.18" x 1.18")
- Rod thread: M6x1.0 male
- Protection rating: IP65 (standard wiper seal)
- Lubrication: Pre-lubricated (maintenance-free for 5,000 km)
Ultra-compact cylinder featuring a space-saving 20mm diameter body with multi-directional mounting capability. Precision-engineered with dual piston guides for enhanced stability in lateral force applications. The magnetic piston enables position sensing compatibility (sensor not included). Optimized air consumption design reduces operating costs by 18% compared to standard cylinders.
- PCB handling robots in electronics manufacturing
- Precision clamping in CNC fixture systems
- Valve actuation in medical analyzers
- Cartesian coordinate automation modules
- Automatic door locking mechanisms
Installation best practices:
Use torque-controlled tightening (0.8-1.2 N·m for mounting screws). Maintain 0.5mm minimum clearance between magnetic sensor and cylinder body. For vertical mounting, install air ports downward to prevent condensation accumulation. Always perform stroke-end cushion adjustment under actual load conditions.
Replacement cycle: Lubricate every 3 million cycles in high-frequency applications
| Property | Property Value |
|---|---|
| sku | MUR12X15B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
