Airtac MUR Compact Free Mount Cylinder MUR12X20
$23.69
Regular price
$31.19
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MUR12X20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
Maintenance note:
Lubricate with ISO VG32 turbine oil through air line lubricator.
Avoid side load exceeding 2N·m. Max lateral rod play: ±0.5mm.
Cycle rate ≤5Hz for optimal seal life.
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Cylinder MUR12X20 Technical Details
- Model: MUR12X20 (Free Mounting Type)
- Bore size: 12mm (Precision honed cylinder tube)
- Stroke: 20mm (±1mm tolerance)
- Action type: Double acting (air consumption: 1.13cm³/stroke at 0.5MPa)
- Installation: Multi-mount capable (Front flange, foot, side/end clevis)
- Operating pressure: 0.15–0.8 MPa (1.5–8 bar)
- Max thrust: 9.05N at 0.5MPa (Calculated with 80% efficiency)
- Buffer type: Adjustable rubber cushion (3mm adjustment range)
- Temperature range: -20℃ to 80℃ (Dry air required below 0℃)
- Seal material: NBR standard (Optional PU seals for -10℃~110℃)
- Port size: M5x0.8 (Rc1/8 adapter available)
- Piston rod thread: M5x0.8 (6mm rod diameter)
- Weight: 0.15kg (Without accessories)
- Dimensions: 60mm(L) × 30mm(W) × 30mm(H) (Stroke-end to rod end)
- Material: Aluminum alloy body (Anodized surface)
- ISO standard: Compliant with ISO 6432 (2015 edition)
Ultra-compact cylinder optimized for space-critical automation systems, featuring 360° adjustable mounting points and precision-ground rod guides. The dual piston seal design ensures ≤0.1mm/sec creep speed under load. Compatible with AT/AD series magnetic switches (sensor slot included).
Ideal Applications:
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical packaging
- Lens positioning stages in optical equipment
- 3D printer nozzle control mechanisms
- Lab automation sample tray indexers
Maintenance note:
Lubricate with ISO VG32 turbine oil through air line lubricator.
Avoid side load exceeding 2N·m. Max lateral rod play: ±0.5mm.
Cycle rate ≤5Hz for optimal seal life.
| Property | Property Value |
|---|---|
| sku | MUR12X20 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
