Airtac MUR Compact Free Mount Cylinder MUR12X20B
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR12X20B Compact Free Mount Cylinder Specifications
- Model: MUR12X20B
- Type: Double-acting free mount mini cylinder
- Bore size: 12mm (0.47")
- Stroke: 20mm (0.79")
- Operation: Air pressure 0.15-0.9 MPa (21.7-130.5 PSI)
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Mounting: 4x M3 threaded holes (side/end mounting)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile) with grease retention design
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 0.25kg (0.55lbs)
- Dimensions: 80mm(L) × 32mm(W) × 32mm(H)
- ISO standard: 6432 (compact cylinder specifications)
Ultra-compact pneumatic cylinder featuring 360° free mounting capability through multi-directional threaded holes. Precision-engineered with anti-rotation rod and wear-resistant guide bushings, optimized for high-cycle applications. Integrated mounting grooves allow direct sensor attachment for position feedback.
- PCB handling robots in electronics assembly
- Micro-dosing valves in pharmaceutical equipment
- Lens positioning systems in optical manufacturing
- Carton flap control in packaging machinery
- Dental chair adjustment mechanisms
Installation note:
Maximum side load capacity 5N. Use M3 screws with 0.6Nm torque limit.
For vertical mounting, install rod end downward to prevent dust accumulation.
Lubricate with ISO VG32 turbine oil before initial use.
| Property | Property Value |
|---|---|
| sku | MUR12X20B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
