Airtac MUR Compact Free Mount Cylinder MUR12X25B
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR12X25B Compact Free Mount Cylinder Specifications
- Model: MUR12X25B
- Type: Single-acting spring return (Push type)
- Bore size: 12mm (0.47")
- Stroke: 25mm (0.98") ±0.5mm tolerance
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushion type: Rubber buffer
- Mounting style: Free installation (optional foot/face mounting)
- Port size: M5x0.8 (dual ports)
- Piston rod thread: M6x1 external thread
- Operating temperature: -10℃ to 70℃ (14°F to 158°F)
- Body material: Aluminum alloy (anodized finish)
- Seal material: NBR + Polyurethane hybrid seals
- Weight: 0.15kg (0.33lbs)
- Dimensions: 80mm(L) × 12mm(W) × 12mm(H)
- Rod end play: ≤0.4mm radial clearance
- Protection rating: IP40 (standard)
Ultra-compact cylinder optimized for space-constrained automation systems, featuring dual-position sensing slots for magnetic switch compatibility (sensors sold separately). The dual-port design allows flexible pneumatic circuit configuration. Precision honed tube ensures ≤0.01mm inner diameter tolerance for smooth operation.
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical packaging
- Optical lens positioning mechanisms
- 3D printer filament feed control systems
- Laboratory sample tray indexers
Installation guidelines:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
Use C-YPEAK grease (viscosity grade 32) for lubrication. Maximum lateral load: 2.5N at full extension.
Requires 5μm filtered air with 1-5 drops/m³ lubricator oil (ISO VG32 equivalent).
| Property | Property Value |
|---|---|
| sku | MUR12X25B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
