Airtac MUR Compact Free Mount Cylinder MUR12X25SB
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Free Mount Cylinder MUR12X25SB Specifications
- Model: MUR12X25SB
- Series: MUR (Compact Free Mount Type)
- Bore size: 12mm
- Stroke: 25mm
- Mounting type: Basic type (Free mounting with optional accessories)
- Action type: Double-acting
- Port size: M5x0.8 (Standard) / NPT1/8 (Optional)
- Operating pressure: 0.05–0.9 MPa
- Cushion type: Rubber buffer (Both ends)
- Piston rod thread: M5x0.8
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile Butadiene Rubber)
- Protection rating: IP65 (Dust-tight & water jet resistant)
- Weight: 0.15 kg (Body only) / 0.18 kg (With accessories)
- Dimensions:
- Length: 85mm (Min. retracted length: 60mm)
- Width: 30mm (Mounting base width)
- Height: 32mm (Including piston rod protrusion)
Ultra-compact cylinder featuring space-saving design with 12mm bore diameter and 25mm stroke length. The anodized aluminum construction ensures corrosion resistance while maintaining lightweight performance (190g max). Precision-ground piston rod with chrome plating enables smooth linear motion. Optional auto-switch grooves (M9/M5) allow sensor integration for position feedback.
- Desktop automation systems requiring micron-level precision
- Semiconductor wafer handling robots
- Medical device actuation mechanisms
- Packaging machine ejector systems
- 3D printer component positioning
Installation tip:
Supports 360° free mounting orientation. For vertical installations,
use lock nuts (ASN12x25) to prevent thread loosening from vibration.
Lubricate with ISO VG32 hydraulic oil if used below -10℃.
| Property | Property Value |
|---|---|
| sku | MUR12X25SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <25 mm> |
