Airtac MUR Compact Free Mount Cylinder MUR12X30
$24.62
Regular price
$32.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MUR12X30
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
Operation tip:
Maintain 0.3-0.5mm clearance between rod end and load during installation.
Use only ISO VG32 hydraulic oil if manual relubrication required. Avoid lateral
forces exceeding 3N during operation.
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Free Mount Cylinder MUR12X30 Technical Details
- Model: MUR12X30
- Type: Single-acting spring return (push type)
- Bore size: 12mm (±0.1mm tolerance)
- Stroke: 30mm (adjustable cushion)
- Mounting style: Free position (non-axial load)
- Operating pressure: 0.05-0.9 MPa
- Cushion type: Rubber buffer + adjustable shock absorber
- Port size: M5×0.8 (Rc1/8 adapter optional)
- Piston rod thread: M6×1.0 (standard)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel (anodized), CR-Mo steel rod (hard chrome plated)
- Seal material: NBR (nitrile) with wear-resistant ring
- Weight: 0.25kg (without accessories)
- Dimensions: 76mm(L) × 20mm(W) × 20mm(H) (minimum retracted length)
- Max speed: 500mm/s (with cushioning)
- Lubrication: Pre-lubricated (maintenance-free for 5,000km stroke)
Ultra-compact pneumatic cylinder featuring space-saving cube-shaped design with 360° adjustable mounting points. The dual-cushion system reduces impact noise below 75dB while maintaining 0.5mm positioning repeatability. Nickel-plated end caps prevent corrosion in humid environments.
Ideal for:
- PCB handling robots requiring precise micro-movements
- Pharmaceutical tablet counting/packaging machines
- Semiconductor wafer transfer mechanisms
- Compact door locking systems in cleanrooms
- Automated microscope stage positioning
Operation tip:
Maintain 0.3-0.5mm clearance between rod end and load during installation.
Use only ISO VG32 hydraulic oil if manual relubrication required. Avoid lateral
forces exceeding 3N during operation.
Environmental compliance:
- RoHS 2.0 compliant (2015/863/EU)
- IP54 protection standard (dust/water resistant)
- Vibration resistance: 10-200Hz @ 1.5mm amplitude
| Property | Property Value |
|---|---|
| sku | MUR12X30 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
