Airtac MUR Compact Free Mount Cylinder MUR12X30B
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR12X30B Compact Free Mount Cylinder Specifications
- Model: MUR12X30B
- Bore size: 12mm (ISO 6432 standard)
- Stroke: 30mm (±0.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Rubber buffer (both ends)
- Mounting style: Free mount with 4x M3 threaded holes
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal type: NBR seals (-10℃ to 80℃)
- Ambient temperature: -10℃ to 60℃
- Max speed: 500mm/s
- Weight: 210g ±5g
- Dimensions:
- Length: 95mm (full retracted)
- Width: 25mm (body diameter)
- Height: 25mm (mounting surface to rod end)
- ISO certification: Compliant with ISO 6432:2015
Ultra-compact pneumatic cylinder featuring space-saving design with integrated mounting threads. Precision-ground rod guide ensures smooth linear motion, while the double-acting operation allows bidirectional force application. Includes magnetic piston for sensor compatibility (inductive sensor not included).
- Desktop automation systems requiring micron-level positioning
- Medical device actuation (ventilator valves, biopsy mechanisms)
- Semiconductor wafer handling robots
- Packaging machine gripper controls
- 3D printer auxiliary mechanisms
Installation protocol:
Apply 0.1-0.3Nm torque during mounting screw tightening. For vertical installations,
use rod-down orientation to prevent piston self-weight extension. Lubricate
rod weekly with ISO VG32 hydraulic oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | MUR12X30B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 30mm |
