Airtac MUR Compact Free Mount Cylinder MUR12X35
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Cylinder MUR12X35 Technical Details
- Model: MUR12X35
- Type: Single-acting spring return (Free mount type)
- Bore size: 12mm
- Stroke: 35mm (standard), customizable 5-100mm
- Operating pressure: 0.05-0.9 MPa
- Port size: M5x0.8 (standard), optional NPT1/8
- Cushioning: Adjustable rubber buffer
- Mounting: Non-rod side tapped holes (M4x0.7, 4 places)
- Temperature range: -10℃ to 80℃
- Cylinder material: Aluminum alloy (anodized)
- Piston rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Weight: 180g ±5% (without accessories)
- Dimensions:
- Length: 110mm (min. retracted length)
- Width: 22mm (main body diameter)
- Height: 28mm (including mounting flange)
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-compact cylinder with space-saving 16mm square body profile, featuring omnidirectional mounting capability through 4x M4 threaded holes. The double-sealing structure ensures IP54 protection against particulate contamination. Optimized for low-friction movement with precision honed tube (Ra≤0.4μm). Includes magnetic piston for sensor compatibility.
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Automated test equipment positioners
- Semiconductor wafer cassette elevators
- Compact packaging machine grippers
Installation tip:
Maintain 0.5mm minimum clearance between cylinder body and adjacent components for heat dissipation.
Use class 8.8 or higher mounting screws with 0.6-0.8Nm torque specification.
| Property | Property Value |
|---|---|
| sku | MUR12X35 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | 35mm |
