Airtac MUR Compact Free Mount Cylinder MUR12X40
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR12X40 Compact Free Mount Cylinder Specifications
- Model: MUR12X40
- Bore size: 12mm
- Stroke: 40mm (±1mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Cushioning: Fixed rubber bumper (both ends)
- Mounting type: Free mounting (no specific orientation required)
- Port size: M5x0.8 (standard) with NPT1/8 adapter option
- Rod material: SUS304 stainless steel
- Cylinder tube: Aluminum alloy (hard anodized)
- Seals: NBR (standard), optional FKM for high temp
- Weight: 190g ±5g
- Dimensions:
- Length: 83mm (full retraction)
- Width: 32mm (including mounting bosses)
- Height: 32mm (square body profile)
- ISO standard: 6432 (compatible with major brands)
Ultra-compact pneumatic cylinder featuring space-saving cube-shaped design with 360° adjustable mounting capability. Precision-machined components ensure smooth operation and minimal stick-slip effect. Integrated auto switch groove (4-2.5mm) simplifies sensor installation. Optimized for low friction operation with self-lubricating rod bearings.
- PCB handling robots in electronics assembly
- Precision door locking mechanisms
- Medical device actuation systems
- Food packaging gripper positioning
- Semiconductor wafer transfer units
Installation tip:
Utilize the 4x M3 threaded mounting holes (6mm depth) for secure fixation.
For vertical installations, add drip protection caps to air ports. Lubricate every
500km stroke travel using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | MUR12X40 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <40mm> |
