Airtac MUR Compact Free Mount Cylinder MUR12X45
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Cylinder MUR12X45 Technical Details
- Model: MUR12X45
- Bore size: 12mm (ISO 6432 standard)
- Stroke: 45mm (customizable 25-200mm)
- Operating pressure: 0.05-1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer
- Mounting style: Free mountable (no fixed mounting bracket)
- Port size: M5x0.8 (standard) with optional NPT1/8 adapters
- Piston rod thread: M5x0.8 external thread
- Material: Aluminum alloy barrel with chrome-plated steel rod
- Seals: NBR/PU compound seals (FDA compliant options available)
- Protection class: IP54 (standard wiper design)
- Weight: 0.23kg (excluding accessories)
- Dimensions:
- Body diameter: 22mm
- Retracted length: 82mm
- Extended length: 127mm
- Rod end protrusion: 12mm (minimum)
Ultra-compact round cylinder featuring symmetrical port design for flexible piping. The anodized surface treatment provides corrosion resistance in humid environments. Its rotation-resistant piston rod (±2° max) ensures precise linear motion. Requires 5μm filtered lubricated air (ISO 8573-1 class 4) for optimal performance.
- Semiconductor wafer handling robots
- Pharmaceutical tablet pressing mechanisms
- Textile machinery thread tension control
- Mobile battery pack assembly systems
- 3D printer automatic bed leveling
Installation guidance:
Apply axial alignment within 0.2mm tolerance during mounting.
Use torque-controlled tightening (1.2-1.5N·m for mounting screws).
Lubricate through air supply (ISO VG32 equivalent) if non-lubricated operation required.
| Property | Property Value |
|---|---|
| sku | MUR12X45 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <45mm> |
