Airtac MUR Compact Free Mount Cylinder MUR12X45SB
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Free Mount Cylinder MUR12X45SB Specifications
- Model: MUR12X45SB
- Bore size: 12mm
- Stroke: 45mm
- Operating pressure: 0.15–0.8 MPa
- Medium temperature: -20℃ to 80℃
- Ambient temperature: -10℃ to 60℃
- Cushion type: Adjustable rubber buffer
- Mounting types: Front flange/rear flange/foot/switch-selectable
- Rod thread: M5×0.8
- Piston speed: 50–800 mm/s
- Port size: M5×0.8 (Rc1/8 adapter optional)
- Seal material: NBR (nitrile rubber)
- Protection rating: IP40
- Weight: 0.22 kg
- Dimensions: 45mm(stroke) × 22mm(Φ) × 64mm(total length)
Ultra-compact pneumatic cylinder with dual-rod design for precise linear motion control. Features anti-rotation mechanism (guide bushing integrated) and multiple mounting options. Chrome-plated piston rod with wear-resistant aluminum alloy body ensures over 3,000km service life under standard conditions.
- PCB handling in SMT machines
- Micro-part positioning in medical device assembly
- Clamping mechanisms in semiconductor testers
- Actuation in automated lab equipment
- Small workpiece ejection systems
Operational guidance:
Lubricate with ISO VG32 hydraulic oil. Maintain 0.5–1.5mm clearance
between rod end and load. Use clean dry air (40μm filtration) with
regular moisture drainage. Avoid side-load forces exceeding 1.5N.
| Property | Property Value |
|---|---|
| sku | MUR12X45SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <45mm> |
