Airtac MUR Compact Free Mount Cylinder MUR12X50S
$30.67
Regular price
$38.17
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MUR12X50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
Installation best practices:
Maintain 1.5mm minimum clearance between cylinder body and adjacent components.
Use torque-limited tools (0.8-1.2 N·m) for mounting screws to prevent tube deformation.
Lubricate with ISO VG32 hydraulic oil if operating below 0.15 MPa.
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Cylinder - MUR12X50S Technical Details
- Model: MUR12X50S
- Bore size: 12mm (0.47")
- Stroke: 50mm (1.97")
- Operation type: Double-acting
- Operating pressure: 0.05–0.9 MPa (7–130 PSI)
- Ambient temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable rubber buffer (both ends)
- Piston speed: 50–800 mm/s
- Port size: M5×0.8 (standard), G1/8 optional
- Mounting style: Free installation (no specific orientation required)
- Rod material: Stainless steel (SUS304)
- Tube material: Aluminum alloy (hard anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 0.28 kg (0.62 lbs)
- Dimensions:
- Length: 123mm (4.84") [retracted]
- Width: 32mm (1.26")
- Height: 32mm (1.26")
- ISO standard: 6432 (compact cylinder specifications)
- Protection class: IP65 (dust-tight & low-pressure water jet resistant)
Ultra-compact cylinder with space-saving cube-shaped design, featuring 360° adjustable mounting points and dual cushioning control. The wear-resistant anodized surface treatment enhances durability in humid environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 4.3.4 air quality standards.
Ideal Applications:
- Desktop automation systems (PCB handling, micro-assembly)
- Medical device actuators (dental chairs, lab automation)
- Food packaging machinery (lightweight clamping/jaws)
- Semiconductor wafer transfer mechanisms
- Robotic end-effector positioning (collaborative robots)
Installation best practices:
Maintain 1.5mm minimum clearance between cylinder body and adjacent components.
Use torque-limited tools (0.8-1.2 N·m) for mounting screws to prevent tube deformation.
Lubricate with ISO VG32 hydraulic oil if operating below 0.15 MPa.
| Property | Property Value |
|---|---|
| sku | MUR12X50S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <50mm> |
