Airtac NPM Clamp Cylinder NPM35T63X13A
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM Series Rodless Cylinder NPM35T63X13A Specifications
- Model: NPM35T63X13A
- Type: Compact guided rodless cylinder (T-slot type)
- Bore size: 35mm
- Stroke: 63mm
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber buffers (both ends)
- Port size: M5x0.8 (standard), optional NPT1/8
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Lubrication: Pre-lubricated (DOP mist lubrication recommended)
- Material: Aluminum alloy body, CRCC steel guide rail
- Seal type: NBR seals with wear-resistant ring
- Weight: 1.4 kg (with standard accessories)
- Dimensions: 252mm(L) × 51mm(W) × 35mm(H)
- Mounting: Standard side mounting holes (M6x1.0)
- Sensor compatibility: Built-in magnet for proximity sensor installation
High-precision rodless cylinder featuring integrated linear guide rails for enhanced moment resistance. The T-slot design allows direct mounting of fixtures/tools, with exceptional position repeatability (±0.2mm). Ideal for vertical Z-axis applications requiring space optimization. Compatible with ISO 15552 mounting accessories.
- PCB handling robots in electronics assembly
- Precision glass panel transfer systems
- Automated dispensing equipment Z-axis control
- Laser marking machine positioning stages
- Medical device component insertion mechanisms
Installation note:
Maintain 0.5-1mm clearance between slider and guide rail during alignment.
Use anti-vibration washers when mounting on dynamic platforms. Lubricate guide rails
with ISO VG32 hydraulic oil every 500km of travel.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13A |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC220V |
| Hydraulic Cylinder Bore | 63mm |
